• This product has been discontinued.

• One-touch automatic setup optimizes the position, range, timebase, and triggering to assure a stable display of virtually any waveform
• Waveform Recorder to capture/replay input waveforms from CH1 and CH2 with a maximum record length of 1000 frames
• Built-in 6,000 count True RMS MultiMeter with analog bargraph
• Easy-to-use pop-up menu with built-in multi-language system
• 23 Automatic Measurements
• Waveform Math: Add, Subtract, Multiply, and Divide
• Store and recall up to 1000 waveform screens and setups using the installed 2G microSD card
• Automatic cursor tracking measurements
• Pass-Fail function compares a stored waveform to an unknown input
• Average Mode for smoothing waveforms
• Built-in FFT function converts a time-domain signal into its frequency components to measure harmonic content and distortion in systems
• Square Wave Output (2V, 1kHz) for probe adjustment
• Complete with two 1X/10X oscilloscope probes, test leads, 7.4V Li-Ion battery, universal AC charger, and carrying case
