Model Number	BHM-X+ (35mm)	BHM-XR+ (35mm)	BHM-X+ (65mm)	BHM-XR+ (65mm)	BHM-X+ (100mm)	BHM-XR+ (100mm)

Thermal Imaging Specifications
Detector Type (VOx Microbolometer)	320 × 240	640 × 480	320 × 240	640 × 480	320 × 240	640 × 480
FOV	13° × 10° NTSC	18° × 13° NTSC	7° × 5° NTSC	10° × 8° NTSC	5° × 3° NTSC	6° × 4° NTSC
Waveband	7.5 - 13.5 μm
Start-up Time (from Stand-by)	< 1.5 seconds
Image Processing	FLIR Proprietary Digital Detail Enhancement
User Interface
Power Button	On/Off/Stand-by
Picture Button	Still image capture and video to SD card
Zoom Button	2× E-zoom	2× & 4× E-zoom	2× E-zoom	2× & 4× E-zoom	2× E-zoom	2× & 4× E-zoom
Polarity	White Hot / Black Hot / InstAlert
Brightness	Adjusts Display Brightness
Image Presentation
Built-in Display	Color LCD Display
Video Output	NTSC or PAL composite video; RCA jack
Video Refresh Rate	<9 Hz or 30 Hz (NTSC and PAL)
Image Polarity	White Hot / Black Hot / InstAlert; Selectable
On-Screen Symbology	Standard
Other
SD Card	Stores still images and video
Power
Battery Type	4 AA Batteries, NiMH, Li-Ion, or Alkaline
Battery Life (Operating)	>5 Hours on NiMH batteries
Battery Life (Stand-by)	120 Hours on NiMH batteries
Environmental
Rating	IP-67, Submersible
Operating Temp.	-4°F to +140°F (-20°C to +50°C)
Storage Temp.	-40°F to +167°F (-40°C to +70°C)
Drop	1 m drop (camera body only)
Physical
Weight (incl. lens & batteries)	.84 lb (1290 g)		3.05 lb (1380 g)		3.06 lb (1390 g)
Size (L × W × H)	10.5” × 6.5” × 2.6”		11.5” × 6.5” × 2.6”		13.0” × 6.5” × 2.6”
Package Includes	Handheld Thermal Camera, Hot Shoe Charging & Video Output Accessory, 4 Rechargeable AA Batteries, AC Power Adapter/Charger, Neck Lanyard, DVD with Operators manual, USB Cable, RCA Video Output Cable, SD Card, Quick Start Guide, Hardshell Case, Tactical Carry Pouch (optional)
Other
Warranty	2 Year Standard; 3/10 Year w/ Registration*
Range Performance
Detect Man (1.8m × 0.5m)	~2,900’ (880 m)	~4,200’ (1.3 km)	~1.0 mi (1.65 km)	~1.4 mi (2.2 km)	~1.5 mi (2.4 km)	~1.8 mi (2.95 mi)
Detect Small Vessel (4.0m × 1.5m)	~1.7 mi (2.7 km)	~2.4 mi (3.9 km)	~3.0 mi (4.9 km)	~4.0 mi (6.5 km)	~4.4 mi (7.1 km)	~5.5 mi (8.8 km)
