1MHz to 3GHz Measurement Frequency Impedance Analyzer with 0.5ms Test Speed and 0.07% Variability

Hioki LCR Meters and Impedance Analyzers range from 1mHz to 3GHz devices to suit a wide range of applications in the testing of electronic components. The IM7587 Impedance Analyzer offers a top measurement time of 0.5ms over a 1MHz to 3GHz frequency range and superior stability, making it ideal for R&D as well as high volume production of ferrite chip beads and chip inductors. Key Features • 1 MHz to 3 GHz testing source frequency • Fastest test speed of 0.5 msec (Analog measurement time) • 0.07% measured value variability (When measuring a 1 nH coil at 3 GHz) • ±0.65% rdg. basic accuracy • Half-rack size body and palm-sized test head • Comprehensive contact check (via DCR testing, Hi-Z reject or waveform judgment) • Make frequency sweeps, level sweeps and time interval measurements in Analyzer Mode

Download datasheet
