Key Features • Switch between voltmeter and battery tester while testing • 264 channels max. (2-wire) to 72 channels max. (4-terminal pair) • Circuit design friendly for impedance measurements that minimize errors between channels (Effect: 0.01% f.s.*) * For BT4560 100 mΩ range, R measurements, and a measurement frequency of 1 kHz • For OCV measurement, internal resistance measurement, and external potential measurement of battery cells • Measure battery modules up to 60 V DC
