| Conductor size | Ø68mm |
|---|---|
| Rated current | 10A (rms) AC (14.1Apeak) |
| Output voltage | 500mV AC/10A AC |
| Accuracy | ±1.0%rdg±0.025mV (40Hz - 70Hz) ±4.0%rdg±0.025mV (30Hz - 5kHz, with inputs of 100mA or more) |
| Phase shift | within 1.0% (45 - 70Hz while combining with KEW 5050, under the input of 10% or more of KEW 5050 leakage current range) |
| Cable length | Approx. 3m |
| Output connector | MINI DIN 6pin |
| Output impedance | Approx. 60W or less |
| Applicable standards | IEC 61010-1, IEC 61010-2-032 CAT Ⅲ 300V Pollution degree 2, IEC 61326-1 |
| Operating temperature & humidity range | -10 - 50°C, relative humidity 85% or Less (no condensation) |
| Dimensions | 186(L) × 129(W) × 53(D)mm |
| Weight | Approx. 560g |
| Optional Accessories | 9094 (Carrying case), Instruction manual, Cable marker |
